ASW 008/010K-SH Series Single Phase Hybrid Inverter
Future-proof solar for modest installations
ASW 008/010K-SH Series
More benefits for less input cost
The ASW 008/010K-SH series of single phase hybrid inverters are highly flexible and efficient, designed to make your solar installation adaptable and ready for future expansion. These units support connected batteries and even diesel generators, making them customizable and future-proof products.
With 3 MPPTs, the ASW 008/010K-SH inverters provide higher energy yields and better adaptability to varying site conditions. the ASW 008/010K-SH inverters are with up to 200% power output for 10s during power outages, an IP66 rating, and a rapid switching speed of 10ms.
The ASW 008/010K-SH single phase hybrid inverters come with parallel function for a higher power used in both residential and small commercial scenarios and offer greater benefits at a significantly lower cost, making them a smart investment for long-term energy savings.
Main Benefits
Up to 200% PV array oversizing for
higher energy yields
UPS-level switching time < 10 ms
Lower startup voltage to 50V
Max. 20 A input current per MPPT
3 MPPTs for ultimate PV design flexibility
Multi-source design for black start
ASW 008/010K-SH Series
Key Features
Optimal Performance
• 3 independent MPPTs for flexible and optimized large PV array design
• Max. 20 A input current per MPPT, ideal for bifacial and large area PV modules
• Up to 200% PV array oversizing resulting in higher energy yields
• ShadeSol shadow management
Safe & Reliable
• UPS-level switching time < 10 ms
• IP66 rated design for indoor and outdoor use
• Up to 200% power output for 10s during power outages
• Multi-source design for black start, integrating PV, battery, and generator
User Friendly
• Expandable up to 30 kW in on-grid and off-grid mode
• Compatible with both lead-acid and lithium batteries
• Smart setup, commissioning and monitoring via Solplanet App
Connect and Monitor
App Store
Connect and monitor your battery using our mobile app available in the Apple App Store.
Google Play
Connect and monitor your battery using our mobile app available in the Google Play Store.
